This plant towed laser scraper grader or pull pan is an ejection type. Known as soil preparation equipment for construction of ground sculpture developments and final trim of sports surfaces and the maintenance of these. It is applied in this way for construction and farm industry areas improving plant technology application through soil preparation for water, fertilizer, and chemical  use, this is thought to be most advantageous after construction for players and other citizens when they are moving about the areas. Moving volume of material in a cost affective manner particularly in agriculture while construction limitations are realized when material has to leave sites and access of these areas with wide load or over size machines restricts are in use.

Franks Final Grade   Dugong Manatee ground sculpting plant towed implement for soil preparation on construction and farm sites.

A 1400 series is pictured above & below

Franks Final Grade post to

PO BOX 86

Helensvale 4212

Queensland Australia

Graham Walsh field officer Text email or call to  0403150593 Australian mobile telephone number email         dugongseries@franksfinalgrade.com.au

Youtube click link:0.29 Sec  Dugong 1400 Series

http://www.youtube.com/watch?v=mEKbNkPQ-7E

0.54 Sec Dugong 1400 Series

http://www.youtube.com/watch?v=AU8VzY9AX40



Franks Final Grade Dugong Grader Scraper Pull Pans. Dugong 1400 Series

http://www.youtube.com/user/frankdugong#p/a/u/1/Fpjs5foIjzs

Frank's Final Grade photo slide show  Dugong 1400 Series

http://www.youtube.com/user/frankdugong#p/u/3/YP7pcdd9UBA

Hi I am the grandson of a founding member of an Australia agriculture industry now worth in the billions. I am more than capable of talking to you about  a Dugong implement regarding most farm industries and construction site application inquiries. This implements designing innovations, built with the flow of technology in mind, has a lasting stance or appearance. The scraper and grader or pan is very often laser controlled for ground sculpting, laser leveling / grading or land forming using computer generated designs.

It is named for its most likely visual appearance when working, a Dugong eating on the sea floor, this would be when grading, and when carrying material it would appear to be surfacing for air. These caricature traits come from the innovation when the nesting placement of the reduced hydraulic cylinders 50%  to 3 for the placement on this patented implement.  The innovation brings many things mostly cost saving for consumables in hydraulics or electric actuator technologies. Self contained actuator module technology options that are improving operations  for operators in larger units with two hydraulic cylinders per function, it is not necessarily relevant technology for this single cylinder per function patent. Although these technologies could be applied to this patent to become a leading patent in its field for Australian safety standards. The small size application in this patent is the best example of this for OHAS requirements and applied actuation for control systems using computer generated earth works. Product backup is by electronic cutting file transfer for fast down time.
